TECHNICAL DATA 23
153
Spring preload 8 mm (0.31 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 60 … 66 N/mm (343 … 377 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 63 … 69 N/mm (360 … 394 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 66 … 72 N/mm (377 … 411 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 35 mm (1.38 in)
Riding sag 110 mm (4.33 in)
Fitted length 415 mm (16.34 in)
Damper oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 156)
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, combination switch
(EXC‑F Six Days)
EJOT PT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, emergency OFF switch M4 1 Nm (0.7 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, intake air temperature sen-
sor
M5 3.5 Nm (2.58 lbf ft)
Screw, light switch M5 1 Nm (0.7 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screw, turn signal switch M5 1 Nm (0.7 lbf ft)
Nut, cable on starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Fuel connection on fuel pump M8 10 Nm (7.4 lbf ft)
