KTM 990 SUPERMOTO 2008 User Manual

PARKING LIGHT BULB:
Remove the rubber grommet [2], pull the bulb socket [3] out of the reflector and pull the
bulb out of the bulb socket.
Proceed in the reverse order to mount a new bulb.
HEADLIGHT BULB:
Pull off the connector [4] and remove the rubber cap [5]. Push together the top of the hold-
ing spring [6] and detach it. Remove the bulb.
Proceed in the reverse order to mount a new bulb.
Attach the headlight mask at the bottom, mount the screw and tighten to 10 Nm.
MAINTENANCE WORK ON CHASSIS AND ENGINE »
57
Replacing the headlight lamp
Remove the screws [1], tilt the headlight mask up towards the front and detach at the
bottom.
Never touch the glass of the bulb with your fingers. The glass of the bulb must remain absolutely
free from grease. Heat will otherwise cause the grease to evaporate and settle down on the
reflector.
1
1
2
4
3
5
6
