75
TROUBLESHOOTING »
Indicator lamp blink code
immobilizer
The blink code (immobilizer indicator lamp) specifies the module affected. From the blink rhythm, you can identify a two-digit number,
the so-called blink code.
E.g. blink code 15: lamp blinks 1x short, 1 second pause, 5x short. Other blink codes following a 3 second pause.
BLINKCODE ERROR DESCRIPTION
12 Key not programmed
13 Antenna not connected
14 No response from key
15 Communication with key is working, but Key Code is unknown
16 Key encryption is not ok
21 Immocan not coded, VIN number not yet transfered
31 No request for encryption from KEIHIN ECU
32 Handshake with KEIHIN ECU failed, CAN Bus Error
60 EEPROM Error
