Clutch lever
The clutch lever [1] is fitted on the left hand side of the handle bar. The adjusting screw [A]
is used to change the original position of the clutch lever (see maintenance work on
chassis and engine).
The clutch is hydraulically actuated and adjusts itself automatically.
Hand brake lever
The hand brake lever [3] is mounted on the right side of the handlebar.The basic position
of the handbrake lever can be changed in 5 steps (see Maintenance work on chassis and
engine).
OPERATION INSTRUMENTS »
7
3
A
1
