SERVICE WORK ON THE CHASSIS 51
10.31Cleaning the chain
Warning
Danger of accidents Oil or grease on the tires reduces their grip.
– Remove oil and grease with a suitable cleaning material.
Warning
Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
Info
The service life of the chain depends largely on its maintenance.
400725-01
– Clean the chain regularly and then treat with chain spray.
Chain cleaner ( p. 105)
Off-road chain spray ( p. 105)
10.32Checking the chain tension
Warning
Danger of accidents Danger caused by incorrect chain tension.
–
If the chain tension is too high, the components of the secondary power train (chain, engine sprocket, rear sprocket, bear-
ings in transmission and rear wheel) are under additional load. Apart from premature wear, in extreme cases the chain can
rupture or the countershaft of the transmission can break. On the other hand, if the chain is loose, it can fall off the engine
sprocket or the rear sprocket and block the rear wheel or damage the engine. Check the chain tension and correct if neces-
sary.
Preliminary work
– Raise the motorcycle with the lift stand. ( p. 37)
B01051-10
Main work
– Push the chain at the end of the chain sliding component upwards to measure the
chain tension A.
Info
The lower chain section 1 must be taut.
Chain wear is not always even, so you should repeat this measurement at
different chain positions.
Chain tension 36… 40 mm (1.42… 1.57 in)
» If the chain tension does not meet specifications:
– Adjust the chain tension. ( p. 52)
Subsequent work
– Remove the motorcycle from the lift stand. ( p. 37)
