WHEELS, TIRES 15
161
Guideline
Screw, front fender M6 7 Nm (5.2 lbf ft)
– Operate the hand brake lever repeatedly until the brake lin-
ings are in contact with the brake disc and there is a pressure
point.
– Take the motorcycle off the front lifting gear. ( p. 113)
– Operate the front brake and compress the fork a few times
firmly.
The fork legs straighten.
–
Tighten screws
4
.
Guideline
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Finishing work
– Remove the rear of the motorcycle from the lifting gear.
( p. 110)
15.3 Removing the rear wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 110)
