COMBINATION INSTRUMENT 8
65
8.7 Fuel level display
F01435-10
The fuel tank contents are shown in area
1
of the display.
The fuel level indicator consists of bars. The more bars are lit, the
more fuel is in the fuel tank.
Info
If the fuel level is getting low, the warning Low Fuel Level
will also appear on the display.
The fuel level is displayed with a slight delay to prevent the
indicator from constantly moving while riding.
The fuel level display is not updated while the side stand is
folded out or the emergency off switch is switched off.
Once the side stand is folded up and the emergency OFF
switch is switched on, the fuel level display is next updated
after 2 minutes.
The fuel level display flashes if the combination instrument
does not receive a signal from the fuel level sensor.
