8 COMBINATION INSTRUMENT
66
8.8 Coolant temperature indicator
F01435-11
The coolant temperature display is shown in segment
1
of the
display.
The coolant temperature indicator consists of bars. The more bars
that light up, the hotter the coolant.
Note
Engine failure Overheating damages the engine.
– If the coolant temperature warning is displayed, stop imme-
diately and take care not to endanger yourself or other traffic
participants in the process.
–
Allow the engine and cooling system to cool down.
– Check and, if necessary, correct the coolant level on the cool-
ing system while it is in a cooled state.
Info
When all the bars light up, the warning High Coolant Tem-
perature appears on the display.
If the cooling system overheats, the maximum engine
speed is limited.
Possible states
• The engine is cold – Up to three bars light up.
• Engine warm – Four to ten bars light up.
