23 TECHNICAL DATA
240
Spring preload
Standard 4 clicks
Static sag 15 mm (0.59 in)
Riding sag 45 … 50 mm (1.77 … 1.97 in)
Fitted length 304 mm (11.97 in)
23.9 Chassis tightening torques
Screw, chain guard EJOT PT
®
K60x30 4 Nm (3 lbf ft)
Remaining screws, chassis M4 4 Nm (3 lbf ft)
Screw, engine electronics control
unit
M4 3 Nm (2.2 lbf ft)
Nut, chain guard M5 7 Nm (5.2 lbf ft)
Nut, reflector on retaining plate M5 5 Nm (3.7 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, anti-rotation lock, handle-
bar stub
M5 4 Nm (3 lbf ft)
Screw, battery compartment M5 4 Nm (3 lbf ft)
Screw, cover in front of battery
compartment
M5 4 Nm (3 lbf ft)
Screw, fuel tank cover M5 4 Nm (3 lbf ft)
