3ASSEMBLY INSTRUCTIONS
BContents of Accessory Case
A : Rear mount type ROPS / B : Mid mount type ROPS
No. DESCRIPTION
UNIT
No. DESCRIPTION
UNIT
AB AB
1
OPERATOR'S MANUAL 1 1 14 PAD (STEERING) 1 1
WARRANTY STATEMENT 1 1
15
GRIP (ORANGE 83) 1 1
ASSEMBLY INSTRUCTIONS 1 1 GRIP (YELLOW 63) 1 1
FILTER WRENCH 1 1 GRIP (BLACK 63) 1 1
SLOW BLOW FUSE (50A) 1 1 GRIP (ORANGE 63) 1 1
STARTER KEY 2 2 LEVER GRIP (MAIN GEAR SHIFT) 1 1
2 CLUTCH SPACER 1 1 16 HOLDER (TOP LINK) 1 1
3 COVER (FENDER TAIL) 2 2 17 HITCH (FRONT) 1 1
4
LIGHT ASSY. (COMB. REAR RH) 1 1 18 PIN ASSY. (FRONT HITCH) 1 1
LIGHT ASSY. (COMB. REAR LH) 1 1 19 REARVIEW MIRROR 1 1
5
STAY (TAIL COVER RH) 1 1 20 STAY (REARVIEW MIRROR) 1 1
STAY (TAIL COVER LH) 1 1 21 SEAT UPPER SUPPORT 2 2
6 LIGHT ASSY. (COMB. FRONT) 2 2
22
COVER (ROPS RH) 1 1
7
STAY (FRONT WINKER RH) 1 1 COVER (ROPS LH) 1 1
STAY (FRONT WINKER LH) 1 1 23 HUB, WHEEL ASSY. 2 2
8 COVER (PTO) 1 1 24 CORD CLAMP 2 2
9 LICENSE LIGHT HOLDER 1 1 25 CORD BAND 1 1
10 LICENSE HOLDER STAY 1 1 26 CORD BAND 2 2
11 STAY (TRAILER SOCKET) 1 1 27 SET PIN 2 2
12 LIGHT ASSY. (LICENSE) 1 1 28 DRAWBAR PIN ASSY. 1 1
13 STAY (LICENSE LIGHT) 1 1
