OPERATING THE MACHINE18
STARTING
BOperator's Seat
To avoid serious injury:
A Make sure that the seat is completely secured
after each adjustment.
A Do not allow any person other than the
operator to ride on the machine.
C Travel adjustment
The operator's seat position can be adjusted forward and
backward by 150 mm (6 in.) range by pulling the seat
sliding lever.
A After adjusting the operator's seat, be sure to check
that the seat is properly locked.
C Suspension adjustment
Turn the suspension adjust knob to achieve the optimum
suspension setting.
BHead Light Switch
(A)......Head lights ON.
(B)......Head lights OFF.
1. Adjust the operator's position.
(1) Seat sliding lever
(1) Suspension adjust knob (A) To decrease tension
(B) To increase tension
2. Select Light Switch Positions
(1) Head light switch
To Next Page
