PERIODIC SERVICE48
BChecking Movable Parts
If any of the movable parts, such as levers and pedals, is
not smoothly moved because of rust or anything sticky, do
not attempt to force it into motion.
In the above case, remove the rust or the sticky thing, and
apply oil or grease on the relevant spot.
Otherwise, the machine may get damaged.
EVERY 25 HOURS
BCleaning Precleaner and Air Cleaner
Paper Element
[GR2020G]
A Operating in dusty conditions requires more frequent
maintenance.
1. Stop the engine and apply the parking brake.
2. Loosen the cover retaining knob and remove the
cover.
3. Inspect the foam precleaner without removing it.
A Do not wash the paper element.
[If the foam precleaner is dirty]
1. Remove the precleaner.
(1) Cover retaining knob
(2) Cover
(1) Element cover nut
(2) Element cover
(3) Precleaner
(4) Paper element
To Next Page
