PARTS
OM 0297SB-AU
31
CHUTE WITH DEFLECTOR
REF. DESCRIPTION QTY PART # CODE
1 Chute assembly – for Kubota US 1 70060-03149 657319
- for Kubota Canada 1 70060-03145 657310
2 Knob 5/16"NC 2 70060-01419 657309
3 Flat washer nylon 11/32" dia. 2 70060-03052 658467
4 Carriage bolt 5/16"NC x 1" 2 O/L O/L
5 Flat washer nylon 7/16" dia. 2 70060-03053 658468
6 Hand guard 1 70060-01358 657308
7 Hex. bolt 1/4"NC x 3/4" 2 O/L O/L
8 Flat washer 5/16" dia. 2 O/L O/L
9 Lockwasher 1/4" 10 O/L O/L
10 Hex. nut 1/4"NC 10 O/L O/L
11 Rotation bushing 1 70060-01357 657338
12 Retaining plate 4 70060-01353 657333
13 Hex. bolt 1/4"NC x 1/2" 6 O/L O/L
Hex. bolt 1/4"NC x 3/4" 2 O/L O/L
