INSTRUMENT PANEL AND CONTROLS
INSTRUMENT PANEL, SWITCHES AND CONTROLS
Illustrated contents
(1) Choke knob (
T2290KW, T2290KWT)............................................ 23
(2) Throttle lever.................................................................................. 23
(3) Brake pedal.................................................................................... 22
(4) Light switch .................................................................................... 28
(5) Hour meter..................................................................................... 30
(6) Parking brake lock knob ................................................................ 22
(7) KRA system override switch .......................................................... 34
(8) Cruise control knob........................................................................ 29
(9) PTO switch..................................................................................... 34
(10) Key switch...................................................................................... 23
(11) Speed control pedal (forward) ....................................................... 29
(12) Speed control pedal (rearward) ..................................................... 29
Illustrated contents
(13) 12 V electrical outlet
(14) Cutting height control dial ......................................................... 32
(15) Lift lever .................................................................................... 28
INSTRUMENT PANEL, SWITCHES AND CONTROLS
INSTRUMENT PANEL AND CONTROLS
T2090BR-AU,T2290KW-AU,T2290KWT-AU
