13
Right handlebar switch
NOTE: The starter motor will not engage unless a brake le-
ver is squeezed at the same time the starter button is pressed.
Electric starter button
22
22
2:
Press the electric starter button to activate the starter motor.
Engine stop switch
11
11
1:
The engine stop switch turns off the ignition, stopping the en-
gine. The scooter’s lights and horn still function.
To prevent damage to the starter motor, do not operate
the starter motor for more than five seconds at a time. If
the scooter fails to start immediately, check the fuel level
and the battery condition, and allow the starter motor to
cool before attempting to start the engine again.
CONTROLS & FEATURES
Left handlebar switch
Headlamp switch -- UP
33
33
3:
The upper switch position turns the headlight high beam on.
The high beam indicator light on the dash is activated as well.
Headlamp switch -- DOWN
44
44
4:
The lower switch position turns the headlight low beam on.
Passing light button - PRESS DOWN
55
55
5:
When downward pressure is applied to the headlight rocker
switch, the high beam is activated. When pressure is released,
the low beam setting is restored. This enables you to rapidly flick
the headlight high beam on and off to signal other vehicles that
you wish to pass.
11
11
1
22
22
2
33
33
3
44
44
4
55
55
5
