12. FRONT WHEEL/FRONT BRAKE/FRONT
SUSPENSION/STEERING SYSTEM
12-2
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Remove the machine frame covers before removing the front wheel. Jack the machine front
wheel off the ground and be careful to prevent the machine from falling down.
• During servicing, keep oil or grease off the brake drum and brake linings.
• Inspect the brake system before riding.
SPECIFICATIONS mm (in)
Ite
m
Standar
d
Service Limit
Radial
⎯
2
(
0.08
)
Front wheel rim run out
Axial
⎯
2
(
0.08
)
Front brake drum I.D 85～85.5
(
3.4～3.42
)
84
(
3.36
)
Front brake linin
g
thickness 4
(
0.16
)
2
(
0.08
)
Tie rod len
g
th 254.5～255.5
(
10.18～10.22
)
⎯
Rod-end
(
tie rod
)
an
g
le 15
º
±
3
º
⎯
TORQUE VALUES
Steering stem nut 70 N-m (7 kgf-m, 50 lbf-ft)
Swing arm nut 45 N-m (4.5 kgf-m, 32 lbf-ft)
Knuckle arm nut 50 N-m (5 kgf-m, 36 lbf-ft)
Front wheel nut 45 N-m (4.5 kgf-m, 32 lbf-ft)
Front wheel hub nut 60 N-m (6 kgf-m, 43 lbf-ft)
Front shock absorber upper mount bolt 40 N-m (4 kgf-m, 29 lbf-ft)
Front shock absorber lower mount bolt 40 N-m (4 kgf-m, 29 lbf-ft)
