2LV/2L1/2L2/2MS/2MT
1-4-11
1040 PF lift motor 3 error
(paper feeder)
After cassette 4 is inserted,
PF lift sensor 3 does not turn
on. This error is detected four
times successively.
Defective bottom
plate elevation
mechanism in the
cassette.
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 3 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of the PF lift
motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF lift
motor.
Replace the PF lift motor 3.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1050 PF lift motor 4 error
(paper feeder)
After cassette 5 is inserted,
PF lift sensor 4 does not turn
on. This error is detected four
times successively.
Defective bottom
plate elevation
mechanism in the
cassette.
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 4 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of the PF lift
motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF lift
motor.
Replace the PF lift motor 4.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1140 BPF lift motor upward error
(Bulk paper feeder)
BPF lift maximum sensor
does not turn on.
The lock signal of the motor is
detected continuously three
times.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
BPF lift motor and BPF main PWB
Defective drive
transmission sys-
tem of the motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective BPF lift
motor.
Replace the BPF lift motor.
Defective BPF
main PWB.
Replace the BPF main PWB (Refer to the
service manual for the paper feeder).
Code Contents Causes
Check procedures/
corrective measures
To Next Page
