2PK/2PL/2PM/2PN
1-1-2
Output tray capacity 150 sheets (80g/m
2
)
Continuous copying 1 to 999 sheets
Light source Exposure lamp (LED)
Scanning system Flat bed scanning by CCD image sensor
Photoconductor OPC drum (diameter 30 mm)
Image write system Semiconductor laser
Charging system Scorotron (positive charging)
Developing system
Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system Transfer roller (negative chargeing)
Separation system Small diameter separation, discharger electrode
Cleaning system Drum: Counter blade
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system
Heat and pressure fusing with the heat roller and the press roller
Heat source: halogen heater
Abnormally high temperature protection devices: thermostat
CPU PowerPC465S (667MHz)
Main
memory
Standard 512 MB
Maximum 1536 MB
Interface
Standard
USB interface connector: 1 (USB 2.0)
USB host: 1
Network interface: 1 (10BASE-T/100BASE-TX/1000BASE-T)
Option eKUIO slot: 1 (It uses it by fax in 4in1 model.)
Resolution
Reading 600 × 600 dpi
Writing 600 × 600 dpi
Operating envi-
ronment
Tempera-
ture
10 to 32.5 °C/50 to 90.5 °F
Humidity 15 to 80% RH
Altitude 2,500 m/8,202 ft or less
Bright-
ness
1,500 lux or less
Dimensions (W × D × H)
494 × 410 × 366 mm
19 7/16 × 16 1/8 × 14 7/16”
(When using the original cover)
494 × 430 × 448 mm
19 7/16 × 16 15/16 × 17 1/4”
(When using the DP)
Weight
(with toner container)
15 kg / 33.1 lb (with original cover)
18 kg / 39.7 lb (with DP)
Space required (W × D)
(using MP tray)
494 × 613 mm
19 7/16 × 24 1/8”
494 × 633 mm
19 7/16 × 24 15/16”
Item
Specifications
3 in 1 model (without FAX) 4 in 1 model (with FAX)
30ppm 35ppm 30ppm 35ppm
