2PK/2PL/2PM/2PN
2-3-13
YC103 1 +12V I 12 V DC 12 V DC power source
Connected to
the control
PWB
2 GND - - Ground
3 HPSW I 0/3.3 V DC Home position sensor: On/Off
4 GND - - Ground
5 NC - - Not used
6 LAMP I 0/24 V DC Exposure lamp drive signal
YC104 1 SCMOT1A O 0/24 V DC (pulse) ISU motor drive pulse
Connected to
the ISU
motor
2 SCMOT2A O 0/24 V DC (pulse) ISU motor drive pulse
3 SCMOT1B O 0/24 V DC (pulse) ISU motor drive pulse
4 SCMOT2B O 0/24 V DC (pulse) ISU motor drive pulse
YC105 1 +3.3V3C O 3.3 V DC 3.3 V DC power source
Connected to
the DP driver
PWB
2 GND - - Ground
3 TIMSWN I 0/3.3 V DC DP timing sensor: On/Off
4 ORGSWN I 0/3.3 V DC DP original sensor: On/Off
5 OPSWN I 0/3.3 V DC DP open/close sensor: On/Off
6 DPDETN I 0/3.3 V DC DP installation detection signal
7 RELSOLN O 0/24 V DC DP switchback pressure solenoid:
(Release) On/Off
8 PRESOLN O 0/24 V DC DP switchback pressure solenoid
(Press.): On/Off
9 REVSOL O 0/24 V DC DP switchback feedshift solenoid: On/Off
10 FEEDCL O 0/24 V DC DP paper feed clutch: On/Off
YC108 1 MOT1A O 0/24 V DC (pulse) DP paper feed motor drive pulse
Connected to
the DP driver
PWB
2 MOT2A O 0/24 V DC (pulse) DP paper feed motor drive pulse
3 MOT1B O 0/24 V DC (pulse) DP paper feed motor drive pulse
4 MOT2B O 0/24 V DC (pulse) DP paper feed motor drive pulse
5 +24V3 O 24 V DC 24 V DC power source
6 GND - - Ground
YC109 1 +24V3 O 24 V DC 24 V DC power source
Connected to
the DP driver
PWB
2 GND - - Ground
Connector Pin Signal I/O Voltage Description
To Next Page
