Types of Report
● Some items might not appear, depending on the model type you are using.
Configuration Page
Prints general information and the current configurations of the machine.
Activity Report
Prints a fax transmission and reception report for the last 100 jobs.
Memory List
Prints a list of unsent fax jobs remaining in the machine's memory.
Quick Dial List
Prints a list of scan and fax Quick Dial entries.
Speed Dial List
Prints a list of Speed Dial entries.
● No Sort
Prints the list with the entries sorted by Speed Dial registration number.
● Sort By Name
Prints the list with the entries sorted by name.
Scan Directory List
Prints a list of scan destinations.
Scan Transmission Log
Prints a scan transmission report.
Maintenance Page
Prints the maintenance page.
Top Previous Next
Copyright © 2009
Contents Previous Next Settings

Kyocera FS-C1020MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	- pages per month
Number of print cartridges	4
Scan speed	5 sec/page
Dimensions (WxDxH)	420 x 493 x 476 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	10/100BaseTX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	print, scan
Compatible operating systems	Windows 2000/XP/Server, 2003/Vista/Server 2008, Mac OS X Version 10.2.8
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	MH, MMR (Fax coding method), MR
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	500 sheets
Processor family	ARM
Sound power level (standby)	34 dB
Sound pressure level (printing)	58 dB
Media weight (tray 1)	60–160 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60–105 g/m²
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	25 W
Power consumption (average operating)	1300 W
Market positioning	Business
