Lantronix CoBox-Micro User Manual

CoBox-Mini Test Bed
3-5
Test Bed
The CoBox-Mini Embedded Integration Kit (part number Mini-Kit) includes a test bed
(carrier board) that provides serial and network connections to the Device Server. The test
bed contains diagnostic LEDs, a voltage regulator, a power supply circuit, a reset switch,
TTL to RS-232 and RS-232 to TTL conversion hardware.
The test bed allows software engineers to immediately begin developing and testing
software applications for the Device Server, rather than delaying the process until the
hardware interface for their product is complete.
Figure 3-3: CoBox-Mini Test Bed
CON9
CON1
PWR
CON7
CH1
CON8
CH2
CON4
18
Link
10
1
6
1
5
96
1
5
96
1
10
1
71
1
915
8
red yellow green
LED1
LED2
LED3
LED4
