6.3 Cut & Fill Measurement* (internal Memory active)
Measure to Bench-
mark with prompt
message
Go to menu update
Design Elevation
Measurement to
Benchmark
displayed
Prompt message
measure to target
Measurement to
target displayed
RfID:
BM:
D.Elv:
BM1
100.038m
0.000m
Meas Reference
Change RfID, BM &
D.Elv goto menu
RfID:
BM:
D.Elv:
BM1
100.038m
100.500m
Meas Reference
Change RfID, BM &
D.Elv goto menu
:
:
RfID : BM1
1.235m
5.68m
Meas.Target !
PtID:
Elv.:
SLAB 1
99.563 m
1.710 m
0.937 m
:
Step Key/Screen Description
1.
Press Menu key and select Cut & Fill applica-
tion in the Program sub-menu.
2.
A message "Meas. Reference" with input
Benchmark reduced level value and Design
Elevation is displayed.
3.
Press measuring key to initiate measurement
with respect to the Reference staff / Bench-
mark.
4.
Reference height and distance measurement
is displayed; follow by a message "Meas.
Target!" prompted.
5.
Again, press measure key to start measure-
ment to target point.
6.
The following results are displayed accord-
ingly- target reduced level (RL) / Elevation,
height of target point and cut / fill value at
target point with respect to the Design
reduced level / Design Elevation.
