IdeaPad B460 Hardware Maintenance Manual
1030 Hard disk drive(HDD)/Memory/Mini PCI Express Card slot
compartment cover
For access, remove this FRU:
• “1010 Battery pack” on page 34
Figure 3. Removal steps of HDD/Memory/Mini PCI Express Card slot
compartment cover
Loosen ve screws
1
, but do not remove them.
Remove one screw
2
, and remove the HDD/Memory/Mini PCI Express Card
slot compartment cover in the direction shown by arrow
3
.
1
1
1
1
1
3
2
Step Screw (quantity) Color Torque
2
M2 × 12 mm, at-head, nylok-coated (1) Black 1.6 kgfcm
