IdeaPad B460 Hardware Maintenance Manual
1090 Keyboard bezel
For access, remove these FRUs in order:
• “1010 Battery pack” on page 34
• “1050 Optical drive” on page 38
• “1080 Keyboard” on page 42
Figure 9. Removal steps of keyboard bezel
Remove three screws
1
, seven screws
2
and six screws
3
on the bottom.
3
3
3
3
3
3
2
2
2
2
2
2
2
1
1
1
Step Screw (quantity) Color Torque
1
M2 × 12 mm, at-head, nylok-coated (3) Black 1.6 kgfcm
2
M2 × 5 mm, at-head, nylok-coated (7) Black 1.6 kgfcm
3
M2 × 2.5 mm, at-head, nylok-coated (6) Black 1.6 kgfcm
