IdeaPad B460 Hardware Maintenance Manual
1050 Optical drive
For access, remove this FRU:
• “1010 Battery pack” on page 34
Figure 4. Removal steps of optical drive
Remove the screw
1
, insert a screwdriver into the screw hole and push the
optical drive in the direction shown by arrow
2
. Pull the optical drive out in the
direction shown by arrow
3
.
1
Step Screw (quantity) Color Torque
1
M2 × 3.5 mm, at-head, nylok-coated (1) Black 1.6 kgfcm
3
2
