Lenovo IdeaPad B460
1040 Hard disk drive
For access, remove this FRU:
• “1010 Battery pack” on page 34
• “1030 Hard disk drive(HDD)/Memory/Mini PCI Express Card slot
compartment cover” on page 36
Attention:
• Donotdroptheharddiskdriveorapplyanyphysicalshocktoit. The hard
disk drive is sensitive to physical shock. Improper handling can cause damages
and permanent loss of data.
• Before removing the drive, suggest the customer to backup all the information on
it if possible.
• Never remove the drive while the system is operating or is in suspend mode.
Figure 4. Removal steps of hard disk drive
Remove the screw
1
, pull the tab up in the direction shown by arrows
2
to
remove the hard disk drive from the slot.
2
1
Step Screw (quantity) Color Torque
1
M2 × 6 mm, at-head, nylok-coated (1) Black 1.6 kgfcm
When installing: Make sure that the HDD connector is attached rmly.
