IdeaPad B460 Hardware Maintenance Manual
1150 LCD front bezel
For access, remove these FRUs in order:
• “1010 Battery pack” on page 34
• “1050 Optical drive” on page 38
• “1080 Keyboard” on page 42
• “1090 Keyboard bezel” on page 44
• “1100 LCD unit” on page 48
Figure 15. Removal steps of LCD front bezel
Remove four screws
1
,
2
.
1
1
2
2
Step Screw (quantity) Color Torque
1
M2 × 3.5 mm, at-head, nylok-coated (2) Black 1.6 kgfcm
2
M2 × 5 mm, at-head, nylok-coated (2) Black 1.6 kgfcm
Remove the LCD front bezel in the direction shown by arrows
3
.
3
3
3
3
