Electrical installation
Mains connection
5
102
EDK82MV371 DE/EN/FR 7.0
Fuses and cable cross−sections
Type Mains
Installation acc. to EN 60204−1
FI
1)
Fuse Circuit breaker L1, L2, N, PE
[mm
2
]
E82MV251_2B
E82MV371_2B
2/PE AC or
1/N/PE AC
180 ... 264 V;
45 ... 65 Hz
M10 A C10 A 1.5 ³ 30 mA
1)
Pulse current sensitive or universal−current sensitive earth−leakage circuit breaker
Observe national and regional regulations
If using earth−leakage circuit breakers, observe the following:
ƒ Only install the earth−leakage circuit breaker between supplying mains and drive
controller.
ƒ Earth−leakage circuit breakers can trip incorrectly due to
– capacitive compensation currents flowing in the cable shields during operation
(particularly with long, shielded motor cables),
– simultaneous connection of several controllers to the mains supply.
Dimensioning of mains contactors
Type
Rated current of mains contactor
With starting current limitation
1)
Without starting current limitation
E82MV251_2B
10 A 20 A
E82MV371_2B
Observe national and regional regulations
1)
e.g. current limiting module E82ZJ004
