Technical data
Operation with rated power (normal operation)
3
87
EDK82MV371 DE/EN/FR 7.0
Operation with rated power (normal operation)
The data applies to operation with rated mains voltage and a switching frequency of 8 kHz
(sine). For data and restrictions for other switching frequencies: See operating
instructions.
Type
Power
Rated mains voltage Mains
current [A]
Output current [A]
[kW]
I
rated
I
max
(60 s)
1)
P
rated
E82EV251 0.25
1 N PE AC 230 / 240 V or
2 PE AC 230 / 240 V:
180 V −0 % ... 264 V +0 %
45 Hz −0 % ... 65 Hz +0 %
3.4 1.7 2.5
E82EV371 0.37 5.0 2.4 3.6
1)
Currents for periodic load change: 1 min overcurrent time with I
max
and 2 min base load time with
75 % I
r
