Technical data
Electrical data
EL 1xx CAN/PLC/MPI
4

16
LDCDS−EL100 EN 8.0
4.2 Electrical data
4.2.1 EL 1xx CAN/PLC/MPI
Supply
Type EL xxx
105m 105 106 108 110 110s
Voltage [V] DC 24 (+18 ... 30)
Current at 24 V [A] 0.25 0.3 0.3 0.5 0.5
Power at 24 V [W] 6.0 7.2 7.2 12.0 12.0
Buffer for real−time clock
dated
Typ EL xxx
105m 105 106 108 110 110s
Battery
Service life
[year] 7 (at 25 °C)
CPU and operating system
Typ EL xxx
105m 105 106 108 110 110s
CPU type IntelR Xscale PXA 270
Operating
system
WindowsR CE 5.0
Memory
Typ EL xxx CAN/MPI
105m 105 106 108 110 110s
RAM [MB] 64
Flash [MB] 32
Exchangeable
disk storage
SD/SDHC card slot
1)
Memory
Typ EL xxx PLC
105m 105 106 108 110 110s
RAM [MB] 128
Flash [MB] 64
Exchangeable
disk storage
SD/SDHC card slot
1)
1)
Due to the great variety of SD/SDHC cards available on the market, compatibility cannot be ensured. We do not
know about any restrictions.
