About this documentation
Document history
1
7
LDCDS−EL100 EN 8.0
1.3 Document history
Material number Version Description
13200039 1.0 03/2007 TD29 First edition
13227672 2.0 11/2007 TD29 The "Commissioning" chapter has been expanded by
descriptions on server functionalities
13236340 3.0 04/2008 TD29 Description of type EL 110s and all types with
integrated PLC has been added
13273430 4.0 01/2009 TD29 Amended by description of type EL 112
13327978 5.0 05/2010 TD29 Amended by description of type EL 103 ECO;
description of type EL 112 deleted; adapted BA
according to the new specifications regarding the
Lenze classification and the new specifications of
the units of measurement regulation
13346004 6.0 08/2010 TD29 Corrected CAN connection drawing for EL 103 ECO
13349601 7.0 06/2011 TD29 UL approval and other revisions
13349601 7.1 07/2011 TD29 Pin assignment SUB−D plug corrected
.Hv| 8.0 01/2012 TD29 New chapter "Install fonts"
Tip!
Information and auxiliary devices around the Lenze products can be found in
the download area at
http://www.Lenze.com
1.4 Terminology used
Term In the following text used for
EL 1xx HMI of the EL 100 or EL 100 ECO series
HMI Human Machine Interface
MPI Interface for the SIMATIC S7 automation system from Siemens AG
SD/SDHC card Memory card in the SD/SDHC format
Touchscreen Touch screen terminal
1.5 Conventions used
Type of information Identification Examples/notes
Spelling of numbers
Decimal separator
Point In general, the decimal point is used.
For instance: 1234.56
Text
Program name » « PC software
For example: »Engineer«, »Global Drive
Control« (GDC)
Icons
Page reference Reference to another page with additional
information
For instance: 16 = see page 16
