5 Commissioning
Connecting the mains voltage
EDKMF2133 DE/EN/FR 4.0
64
H2 NetzspgZuschalten-unkontroll Anlauf
Connecting the mains voltage
Note!
If you use the external voltage supply for the communication module, please
switch it on.
The following LEDs at the front of the communication module must be on:
ƒ The top green LED: ”Status display for voltage supply”
ƒ The bottom green LED: ”Status display for drive”
Protection against uncontrolled restart
Note!
In some cases the controller should not restart after a fault (e.g. after a short
mains failure).
ƒ
ThedrivecanbeinhibitedbysettingC0142=0if
– the corresponding controller sets a fault ”LU message” and
– the fault is active for more than 0.5 seconds.
Parameter function:
ƒ
C0142 = 0
– The controller remains inhibited even after the fault has been
eliminated and
– the drive restarts in a controlled mode: LOW-HIGH transition at terminal
28 (CINH)
ƒ
C0142 = 1
– An uncontrolled restart of the controller is possible.
