Function library
Function blocks
3.5.26 Drive control (DCTRL)
3−162
l
EDSVS9332P−EXT DE 2.0
3.5.26.3 Controller inhibit (CINH)
) Note!
When the controller changes to an LU message or an OU message, the signal
DCTRL−CINH is not set.
The power output stages are inhibited. All controllers are reset.
l The function can be controlled via seven inputs:
– Terminal X5/28 (LOW = controller inhibit)
– Control word CAN−CTRL bit 9 of CAN−IN1
– Control word AIF−CTRL bit 9 of AIF−IN
– Control word C0135 bit 9
– MONIT−TRIP (HIGH = A monitoring function that is configured to TRIP has been activated in
the MONIT function block)
– Free input DCTRL−CINH1
– Free input DCTRL−CINH2
l All inputs are linked by an OR−operation.
l C0136/1 indicates the control word C0135
3.5.26.4 TRIP−Set
The drive is lead to the state selected under code C0581 and indicates EEr (external monitoring).
l The function can be controlled by four inputs
– Control word CAN−CTRL bit 10 of CAN−IN1
– Control word AIF−CTRL bit 10 of AIF−IN
– Control word C0135 bit 10
– Free input DCTRL−TRIP−SET
l All inputs are linked by an OR−operation.
l C0136/1 indicates the control word C0135
3.5.26.5 TRIP RESET
Resets a pending trip if the cause of malfunction has been eliminated. If the cause of malfunction is
still active, no response is effected.
l The function can be controlled by four inputs
– Control word CAN−CTRL bit 11 of CAN−IN1
– Control word AIF−CTRL bit 11 of AIF−IN
– Control word C0135 bit 11
– Free input DCTRL−TRIP−RESET
l All inputs are linked by an OR−operation.
l This function is only carried out by a LOW−HIGH edge of the signal resulting from the OR
operation.
l C0136/1 indicates the control word C0135
