Lenze L-force PROFIBUS-DP User Manual

Technical data
Connection terminals
4

17
EDS82ZAFPC010 EN 4.0
4.4 Connection terminals
E82ZAFPC001function module
Terminal strip X3/
VP Level: 5 V (reference: GND3)
Load capacity: I
max
= 10 mA
28 External supply of terminal with
U(ext.) = +12 V DC − 0% ... +30 V DC + 0%
20 DC voltage source for internal supply of controller inhibit (CINH)
U = + 20 V (reference: GND1),
I
max
= 20 mA
59 External supply of function module with
U(ext.) = +24 V DC ± 10%
E82ZAFPC010 function module
Terminal strip X3.2/
59
External supply of function module with
U(ext.) = +24 V DC ± 10%
Terminal strip X3.3/
28 External supply of terminal with
U(ext.) = +12 V DC − 0% ... +30 V DC + 0%
20
DC voltage source for internal supply of controller inhibit (CINH)
U = + 20 V (reference: GND1)
Load capacity: I
max
= 20 mA
