Lenze L-force PROFIBUS-DP User Manual

Parameter data transfer
Parameter set transfer
8

66
EDS82ZAFPC010 EN 4.0
8.2 Parameter set transfer
Lenze parameter sets
The 8200 vector and 8200 motec controllers have 2/4 parameter sets, whose parameters
can directly be addressed with the PROFIBUS.
 Note!
ƒ Parameter set 1 can be accessed via ...
– DRIVECOM parameter data channel
– PROFIdrive parameter data channel (DP−V0)
– PROFIdrive parameter data channel (DP−V1)
ƒ Parameter sets 2 ... 4 can be accessed via ...
– DRIVECOM parameter data channel
– PROFIdrive parameter data channel (DP−V1)
Addressing of Lenze parameter sets
The parameter sets are addressed by means of a code offset:
ƒ Offset 0 addresses parameter set 1 (C0000 ... C1999).
ƒ Offset 2000 addresses parameter set 2 (C2000 ... C3999).
ƒ Offset 4000 addresses parameter set 3 (C4000 ... C5999).
ƒ Offset 6000 addresses parameter set 4 (C6000 ... C7999).
If a parameter is only available once (see documentation for 8200 vector), use the code
offset 0.
Example for C0011 (maximum rotating−field frequency):
ƒ C0011 in parameter set 1: Lenze code number = 11
ƒ C0011 in parameter set 2: Lenze code number = 2011
ƒ C0011 in parameter set 3: Lenze code number = 4011
ƒ C0011 in parameter set 4: Lenze code number = 6011
Parameter set transfer with keypad
 Note!
Always switch the mains after you have transferred the parameter sets with
the keypad!
Observe the options for parameter set transfer with keypad marked with
"Keypad
ð" under code C0002.
If an address is assigned via C1509, the address must be reassigned via the parameter data
channel after a parameter set transfer. Afterwards mains switching is required. The
address modified via keypad becomes effective immediately.
