11.1 Particularities for use in conjunction with Lenze standard devices
Use of function module in conjunction with starttec motor starter
 Note!
If the function module is used in conjunction with the starttec motor starter,
solely the Lenze device control is effective.
In the following table, the bit assignments for the applicable control word 1 (FIF−CTRL1)
and status word 1 (FIF−STAT1) are given:
Control word 1 (FIF−CTRL1) Status word 1 (FIF−STAT1)
Bit Assignment Bit Assignment
0S1 0 Reserved
1 S2 1 Reserved
2 Brake 2 Reserved
3 Reserved 3 Reserved
4 Reserved 4 Reserved
5 Reserved 5 Reserved
6 Reserved 6 Fixed 1
7 Reserved 7 Controller inhibit
0
1
Controller enabled
Controller inhibited
8 Reserved 8 ... 11 Device status
9 Controller inhibit
(FIF−CTRL1−CINH)
0
1
Controller enabled
Controller inhibited
Bit 11 10 9 8
10 External fault
(FIF−CTRL1−TRIP−SET)
0
0
0
1
1
1
1
0
Operation inhibited
Operation enabled
11 Fault reset 1
1
0
1
0
1
0
1
Fault active
Communication with basic
device not possible
0=>1 (FIF−CRTL1−TRIP−RESET)
Bit change causes TRIP reset
12 Reserved 12 Reserved
13 Reserved 13 Reserved
14 Reserved 14 Reserved
15 Reserved 15 Ready for operation
0
1
Not ready for operation (fault)
Ready for operation (no fault)
