Appendix
Parallel operation of AIF and FIF interfaces
11
89
EDS82ZAFPC010 EN 4.0
11.3 Parallel operation of AIF and FIF interfaces
Note!
The option of parallel operation ...
ƒ of a communication module (AIF) and a function module (FIF) exists for the
standard devices 8200 vector and Drive PLC.
ƒ of two function modules (FIF) exists for the standard devices 8200motec,
Drive PLC and starttec.
Possible combinations
Function module on FIF
Communication module on AIF
Keypad E82ZBC
Keypad XT
EMZ9371BC
PROFIBUS−DP
EMF2133IB
System bus
CAN
EMF2171IB
EMF2172IB
CANopen
EMF2178IB
DeviceNet
EMF2179IB
Ethernet
PowerLink
EMF2191IB
Standard I/O PT E82ZAFSC010 ü ü ü ü ü ü
Application I/O PT E82ZAFAC010 ü ü) ü) ü) ü) ü)
PROFIBUS−DP E82ZAFPC010
ü x x x x x
PROFIBUS I/O E82ZAFPC201
Sys. bus CAN PT E82ZAFCC010
ü ü ü ü ü ü
Sys. bus CAN PT E82ZAFCC210
Sys.−bus CAN−I/O RS PT E82ZAFCC100
CANopen PT E82ZAFUC010 ü x x x x x
DeviceNet PT E82ZAFVC010 ü x x x x x
INTERBUS PT E82ZAFIC010 ü x x x x x
LECOM−B PT E82ZAFLC010 ü x x x x x
AS interface PT E82ZAFFC010 ü x x x x x
Function module on FIF
Communication module on AIF
INTERBUS
EMF2113IB
LECOM−A/B
EMF2102IBC V001
LECOM−A
EMF2102IBC V004
LECOM−B
EMF2102IBC V002
LECOM−LI
EMF2102IBC V003
Standard I/O PT E82ZAFSC010 ü ü ü ü ü
Application I/O PT E82ZAFAC010 ü) ü) ü) ü) ü)
PROFIBUS−DP E82ZAFPC010
x ü) ü ü) ü)
PROFIBUS I/O E82ZAFPC201
Sys. bus CAN PT E82ZAFCC010
ü ü ü ü ü
Sys. bus CAN PT E82ZAFCC210
Sys.−bus CAN−I/O RS PT E82ZAFCC100
CANopen PT E82ZAFUC010 x ü) ü ü) ü)
DeviceNet PT E82ZAFVC010 x ü) ü ü) ü)
INTERBUS PT E82ZAFIC010 x ü) ü ü) ü)
LECOM−B PT E82ZAFLC010 x ü) ü ü) ü)
AS interface PT E82ZAFFC010 x ü) ü ü) ü)
ü Combination possible, communication module can be supplied internally or externally
(keypad only internally)
ü Combination possible, communication module has to be supplied externally
x Combination not possible
