Lenze MDEMAXX063-42C1C User Manual

Product description
Identification
Motor code
3
14
Lenze ¯ BA 33.0005 ¯ 5.0
3.1.1 Motor code
Three−phase AC motors MLLMA
Example M D E MA XX 063 − 4 2 C1 C
Meaning Variant Motor code
Product family M
Efficiency class
IE1 D
IE2 H
Cooling
Natural ventilation S
Integral fan E
Blower F
Internal key MA
Built−on accessories
Without built−on accessories XX
Brake BR
Brake + resolver BS
Brake + incremental encoder BI
Brake + sin/cos absolute value encoder BA
Brake + 2nd shaft end BZ
Brake + handwheel BH
Brake + grey iron fan BL
Resolver RS
Incremental encoder IG
Sin/cos absolute value encoder AG
2nd shaft end ZE
Handwheel HA
Grey iron fan LL
Grey iron fan + 2nd shaft end LZ
Grey iron fan + handwheel LH
Size
063
071
080
090
100
112
132
160
180
200
225
Overall length
−
0
1
2
3
4
Number of pole pairs
2−pole motors 1
4−pole motors 2
6−pole motors 3
Design type Internal key C1
Approval
CE C
cURus V
CCC 3
