Mechanical installation
Important notes
5
20
Lenze ¯ BA 33.0005 ¯ 5.0
5 Mechanical installation
5.1 Important notes
 Danger!
Some of the motors mounted to the gearboxes are equipped with
transport aids. They are only intended for the mounting/dismounting of
the motor to the gearbox and must not be used for the entire geared
motor!
¯ Only move the drive with means of transport or hoists that have sufficient
load−bearing capacity.
¯ Ensure safe fixing.
¯ Avoid shocks!
Screw−on dimensions B14 flange
 Stop!
Observe the maximally permissible screw−in depth for B14 flange!
S
C
c max. s
[mm] [mm]
MDERA056 V1 FT65 11 M5
MDERA063 V1 FT75 14 M5
MDERA071 V1 FT85 14 M6
MDERA080 V1 FT100 16 M6
MDERA090 V1 FT115 14 M8
MDERA100 V1 FT130 19 M8
MDERA112 V1 FT130 21 M8
MDERA132 V1 FT165 22 M10
MMAN063 FT75 10 M5
MMAN071 FT85 10 M6
MMAN080 FT100 12 M6
MMAN080 FT130 16 M8
MMAN090 FT115 14 M8
MMAN090 FT130 16 M8
MMAN100 FT130 14 M8
MMAN112 FT130 16 M8
MHERA080 FT100 15 M6
MHERA090 FT115 16 M8
MHERA100 FT130 18 M8
MHERA112 FT130 19 M8
MHERA132 FT165 23 M10
