Appendix
Technical data as specified by ordinances (EU) No. 4/2014 and (EC) No. 640/2009
10
52
Lenze ¯ BA 33.0005 ¯ 5.0
10 Appendix
10.1 Technical data as specified by ordinances (EU) No. 4/2014 and
(EC) No. 640/2009
This chapter includes the technical data in compliance with the specifications laid down
by ordinances (EU) No. 4/2014 and (EC) No. 640/2009.
Annex 1 Clause 2 of ordinance (EC) No. 640/2009 stipulates the publication of the
following technical data in the fixed order 1 ... 12:
No. Meaning
1
Rated efficiency (h) at 100 %, 75 % and 50 % of the rated load and rated voltage (U
rated
)
2 Efficiency level: "IE2" or"IE3"
3 Year of manufacture
4 Name or trademark, official registration number and manufacturer’s place of establishment
5 Model number of the product
6 Number of poles of the motor
7 Rated output power(s) or rated output power interval [kW]
8 Rated input frequency (frequencies) of the motor [Hz]
9 Rated voltage(s) or rated voltage interval [V]
10 Rated speed(s) or rated speed interval [rpm]
11 Relevant information for the disassembly, recycling or disposal after the final decommissioning
12 Information regarding the range of operating conditions for which the motor is specially designed:
i) Altitudes above sea level
ii) Ambient air temperatures, also for motors with air cooling
iii) Cooling fluid temperature at the inlet of the product
iv) Maximum operating temperature
v) Hazardous areas
Technical data in compliance with ordinance (EC) No. 640/2009
No. MHLMA 080...132 motors
1
h
100%
[%] 79.6 82.0 82.8 86.3 85.5 88.3 89.2 88.7
h
75%
[%] 79.6 81.6 83.4 86.7 85.6 88.2 89.3 88.9
h
50%
[%] 74.9 77.4 82.2 85.4 83.8 86.3 88.2 87.6
2 IE2 IE2 IE2 IE2 IE2 IE2 IE2 IE2
3 For year of manufacture and week of manufacture see nameplate: 16
4 Lenze Drives GmbH, Breslauer Straße 3, D−32699 Extertal, GERMANY, HR Lemgo B 6478
5 Motor code MHMA
080−32
MHMA
090−12
MHMA
090−32
MHMA
100−12
MHMA
100−32
MHMA
112−22
MHMA
132−12
MHMA
132−22
6 Number of poles 4 4 4 4 4 4 4 4
7 P
rated
[kW] 0.75 1.1 1.5 2.2 3.0 4.0 5.5 7.5
8 f
r
[Hz] 50 50 50 50 50 50 50 50
9 V
rated
[V] 400 400 400 400 400 400 400 400
10 n
r
[rpm] 1410 1430 1435 1445 1445 1455 1470 1460
11 Information regarding the disposal: 12
12
i) Permissible installation height: 19
ii) Permissible ambient air temperatures: 19
iii) Not relevant, since motors are not liquid−cooled.
iv) Maximum operating temperature: 155 C (temperature class F)
v) Operation in hazardous areas prohibited.
