Lexmark E342n User Manual

4511-xxx
Diagnostics—all models
2-85
Cover interlock switch service check
Note: Make sure a print cartridge assembly is installed and the cover
closes all the way, engaging the cover open switch lever.
FRU Action
Cover interlock switch Disconnect the cover interlock cable from the
controller card at J15.
With the printer turned off, verify continuity
between cable pin 1 and pin 2 with the door
closed and discontinuity with the door open.
Verify continuity between cable pin 1 and pin 3
with the door open and discontinuity with the
door closed.
Verify discontinuity between cable pins 2 and 3
whether the door is open or closed.
• If either fails, replace the cover interlock
switch.
• If both pass continuity, turn the printer on, and
measure +5 V dc on pin 2 at J15 on the
controller card.
• Verify pins 1 and 3 at J15 are ground.
• If voltage or ground is not present, see
“Controller card service check” on
page 2-82 for more information.

Lexmark E342n Specifications

General

Processor frequency	366 MHz
Maximum internal memory	160 MB
Sound power level (standby)	27 dB
Sound pressure level (printing)	52 dB
I/O ports	1x IEEE 1284 Bidirectional Parallel 1x RJ-45 1x USB 2.0
Mac compatibility	Yes
Printer management	Zero configuration, DDNS, mDNS, NTP: Network Time Protocol, ping, finger, telnet, TFTP
Networking features	Ethernet 10/100BaseTx
Standard media sizes	10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal, Letter, Statement, Universal
Compatible operating systems	Red Flag Linux 4.0 Linpus Linux 9.2 Red Hat Enterprise Linux WS 3.0, 4.0 SuSE Linux Enterprise Server 8.0, 9.0 SuSE Linux Professional 9.0, 9.1, 9.2 Debian GNU/Linux 3.0 Linspire Linux 4.5 - Microsoft Windows 2000 (Professional/Server/Advanced Server) Microsoft Windows NT (4.00/4.00 Server) Microsoft Windows Me Microsoft Windows XP (Home, Professional) Microsoft Windows Server 2003 (Standard, Enterprise) Microsoft Windows 98 2nd Edition Microsoft Windows XP Professional x64 Microsoft Windows Server 2003 running Terminal Server Microsoft Windows 2000 Server running Terminal Services - Novell Open Enterprise Server Novell NetWare 5.x, 6.x + iPrint, Novell Distributed Print Services (NDPS) IBM iSeries or IBM AS/400 - Sun Solaris 7, 8, 9, 10 HP-UX 11.00, 11.11 IBM AIX 5.1, 5.2, 5.3 Sun Solaris 7, 8, 9, 10 HP-UX 11.00, 11.11 IBM AIX 5.1, 5.2, 5.3 - Apple Mac OS X Apple Mac OS 9.x
Print quality (black, best quality)	2400 DPI
Color	No
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Maximum input capacity	250 sheets
Maximum print size	210 x 297 mm
Media types supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Media weight (tray 1)	75 gsm
Maximum ISO A-series paper size	A4
Display	LCD
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Maximum duty cycle	15000 pages per month
Package weight	12100 g
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	396 x 353 x 249 mm
Maximum dimensions (W x D x H)	460 x 420 x 355 mm
