Lexmark E342n User Manual

4511-xxx
2-90 Service Manual
LVPS/HVPS service check
FRU Action
LVPS/HVPS
LVPS portion of board
Fuses that open typically indicate a faulty LVPS/
HVPS.
Use the voltage meter to verify the appropriate
voltage at the printer end of the power cable.
Remove the LVPS/HVPS assembly from the
printer. Check continuity on the fuses. If either
fuse has opened, replace the card.
Ensure the switch is off, and plug the power cord
into the card. Turn the switch on.
CAUTION: The card has several points where
AC voltage is exposed.
Carefully verify the AC voltage between pins 1
and 2 of CN102 matches the power cable (wall)
voltage. If voltage is incorrect, replace the card
assembly.
Verify +24 V dc from pin 8 at CN201. If voltage
is incorrect, replace the card assembly.
HVPS portion of board
Problems with the HVPS are exhibited in the
print quality. See “Print quality service
checks” on page 2-98 for more information.

Lexmark E342n Specifications

General

Processor frequency	366 MHz
Maximum internal memory	160 MB
Sound power level (standby)	27 dB
Sound pressure level (printing)	52 dB
I/O ports	1x IEEE 1284 Bidirectional Parallel 1x RJ-45 1x USB 2.0
Mac compatibility	Yes
Printer management	Zero configuration, DDNS, mDNS, NTP: Network Time Protocol, ping, finger, telnet, TFTP
Networking features	Ethernet 10/100BaseTx
Standard media sizes	10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal, Letter, Statement, Universal
Compatible operating systems	Red Flag Linux 4.0 Linpus Linux 9.2 Red Hat Enterprise Linux WS 3.0, 4.0 SuSE Linux Enterprise Server 8.0, 9.0 SuSE Linux Professional 9.0, 9.1, 9.2 Debian GNU/Linux 3.0 Linspire Linux 4.5 - Microsoft Windows 2000 (Professional/Server/Advanced Server) Microsoft Windows NT (4.00/4.00 Server) Microsoft Windows Me Microsoft Windows XP (Home, Professional) Microsoft Windows Server 2003 (Standard, Enterprise) Microsoft Windows 98 2nd Edition Microsoft Windows XP Professional x64 Microsoft Windows Server 2003 running Terminal Server Microsoft Windows 2000 Server running Terminal Services - Novell Open Enterprise Server Novell NetWare 5.x, 6.x + iPrint, Novell Distributed Print Services (NDPS) IBM iSeries or IBM AS/400 - Sun Solaris 7, 8, 9, 10 HP-UX 11.00, 11.11 IBM AIX 5.1, 5.2, 5.3 Sun Solaris 7, 8, 9, 10 HP-UX 11.00, 11.11 IBM AIX 5.1, 5.2, 5.3 - Apple Mac OS X Apple Mac OS 9.x
Print quality (black, best quality)	2400 DPI
Color	No
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Maximum input capacity	250 sheets
Maximum print size	210 x 297 mm
Media types supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Media weight (tray 1)	75 gsm
Maximum ISO A-series paper size	A4
Display	LCD
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Maximum duty cycle	15000 pages per month
Package weight	12100 g
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	396 x 353 x 249 mm
Maximum dimensions (W x D x H)	460 x 420 x 355 mm
