Lexmark E342n User Manual

4511-xxx
Diagnostics—all models
2-91
Main motor service check
FRU Action
Main motor cable
LVPS/HVPS
Controller card
Warning: Do not
replace the operator
panel and controller
card at the same time.
Each card contains the
printer settings. When
either of these cards is
new, it obtains the
settings from the other
card. Settings are lost
when both are new
and replaced at the
same time.
Turn off the printer, and unplug the main motor
cable at J8. Turn on the printer, and check for
the following voltages at J8:
Verify ground at pin 5 for both the card and
cable.
• If these voltages are correct, check the main
motor cable for continuity.
–Remove rear cover to access connector on
motor.
–If continuity exists on each wire, call next
level of service.
–If continuity does not exist on one or more of
the wires, replace the motor cable.
• If these voltages are not correct, see
“Controller card connector pin values” on
page 5-4, or replace the controller card. See
“Controller card removal” on page 4-15.
Note: The main motor is not a service part.
J8 pins Voltages
Pins 1–4
Approx. +3.3 V dc
Pin 6
Approx. +5 V dc
Pins 7–9
10Vdc–24Vdc

Lexmark E342n Specifications

General

Processor frequency	366 MHz
Maximum internal memory	160 MB
Sound power level (standby)	27 dB
Sound pressure level (printing)	52 dB
I/O ports	1x IEEE 1284 Bidirectional Parallel 1x RJ-45 1x USB 2.0
Mac compatibility	Yes
Printer management	Zero configuration, DDNS, mDNS, NTP: Network Time Protocol, ping, finger, telnet, TFTP
Networking features	Ethernet 10/100BaseTx
Standard media sizes	10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal, Letter, Statement, Universal
Compatible operating systems	Red Flag Linux 4.0 Linpus Linux 9.2 Red Hat Enterprise Linux WS 3.0, 4.0 SuSE Linux Enterprise Server 8.0, 9.0 SuSE Linux Professional 9.0, 9.1, 9.2 Debian GNU/Linux 3.0 Linspire Linux 4.5 - Microsoft Windows 2000 (Professional/Server/Advanced Server) Microsoft Windows NT (4.00/4.00 Server) Microsoft Windows Me Microsoft Windows XP (Home, Professional) Microsoft Windows Server 2003 (Standard, Enterprise) Microsoft Windows 98 2nd Edition Microsoft Windows XP Professional x64 Microsoft Windows Server 2003 running Terminal Server Microsoft Windows 2000 Server running Terminal Services - Novell Open Enterprise Server Novell NetWare 5.x, 6.x + iPrint, Novell Distributed Print Services (NDPS) IBM iSeries or IBM AS/400 - Sun Solaris 7, 8, 9, 10 HP-UX 11.00, 11.11 IBM AIX 5.1, 5.2, 5.3 Sun Solaris 7, 8, 9, 10 HP-UX 11.00, 11.11 IBM AIX 5.1, 5.2, 5.3 - Apple Mac OS X Apple Mac OS 9.x
Print quality (black, best quality)	2400 DPI
Color	No
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Maximum input capacity	250 sheets
Maximum print size	210 x 297 mm
Media types supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Media weight (tray 1)	75 gsm
Maximum ISO A-series paper size	A4
Display	LCD
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Maximum duty cycle	15000 pages per month
Package weight	12100 g
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	396 x 353 x 249 mm
Maximum dimensions (W x D x H)	460 x 420 x 355 mm
