DVD Setup
When connecting with a component cable

Connect the video outputs (Y, Pb, Pr) of the DVD to the
COMPONENT IN VIDEO jacks on the TV.

Connect the audio outputs of the DVD to the
COMPONENT IN AUDIO jacks on the TV.

Turn on the DVD player, insert a DVD.

Select Component input source using the INPUT button
on the remote control.

Refer to the DVD player’s manual for operating
instructions.
Component Input ports
To achieve better picture quality, connect a DVD player to the component input ports as shown
below.
Component ports on the TV Y Pb Pr
Video output ports on DVD
player
Y Pb Pr
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
Connecting with a Euro Scart cable

Connect the Euro scart socket of the DVD to the AV1 Euro
scart socket on the TV.

Turn on the DVD player, insert a DVD.

Select AV1 input source using the INPUT button on the
remote control.
If connected to AV2 Euro scart socket, select AV2 input
source.

Refer to the DVD player’s manual for operating
instructions.
NOTE
 Any Euro scart cable used must be signal shielded.
COMPONENT IN
VIDEO
AUDIO
18
EXTERNAL EQUIPMENT SETUP

LG 19LG3000 Specifications

General

Teletext function	Yes
RMS rated power	6 W
Number of speakers	2
Equalizer bands quantity	5
Audio (L/R) in	1
Product color	Black
LED indicators	Stand-by
HD type	WXGA
Display diagonal	19 \
Display brightness	380 cd/m²
Display resolution	1440 x 900 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, vertical	170 °
Viewing angle, horizontal	160 °
Power consumption (standby)	1 W
Power consumption (typical)	56 W

Weight and Dimensions

Depth (with stand)	189.2 mm
Width (with stand)	458.8 mm
Height (with stand)	391 mm
Weight (with stand)	5020 g
Depth (without stand)	69 mm
Height (without stand)	344.5 mm
Weight (without stand)	4760 g
