172
APPENDIX
APPENDIX
01. Power k a 0 0 to 01
02. Aspect Ratio k c Refer to p. 173
03. Screen Mute k d 00 to 01
04. Volume Mute k e 00 to 01
05. Volume Control k f 00 to 64
06. Contrast k g 00 to 64
07. Brightness k h 00 to 64
08. Colour k i 00 to 64
09. Tint k j 00 to 64
10. Sharpness k k 00 to 64
11. OSD Select k l 00 to 01
12.
Remote control lock mode k m 00 to 01
13. Treble k r 00 to 64
14.
Bass k s 00 to 64
15. Balance k t 00 to 64
16.
Colour Temperature k u 00 to 02
17. ISM Method j p Refer to p. 175
18. Energy Saving j q 00 to 04
19. Auto Configuration j u 01
20. Tune Command m a Refer to p. 175
21. Programme Add/Skip m b 00 to 01
22. Key m c Key Code
23. Control Back Light m g 00 to 64
24. Input select (Main) x b Refer to p. 176
Communication Parameters
A
Baud rate : 9600 bps
(
UART
)
A
Data length : 8 bits
A
Parity : None
A
Stop bit : 1 bit
A
Communication code : ASCII code
A
Use a crossed (reverse) cable.
Transmission
*
[Command 1] : First command to control the TV.
(j, k, m or x)
*
[Command 2] : Second command to control the TV.
*
[Set ID] : You can adjust the set ID to choose
desired monitor ID number in option
menu. Adjustment range is 1 to 99.
When selecting Set ID ‘0’, every connect-
ed set is controlled.
Set ID is indicated as decimal (1 to 99) on
menu and as Hexa decimal (0x0 to 0x63)
on transmission/receiving protocol.
*
[DATA] : To transmit command data.
Transmit ‘FF’ data to read status of com-
mand.
*
[Cr] : Carriage Return
ASCII code ‘0x0D’
*
[ ] : ASCII code ‘space (0x20)’
[Command1][Command2][ ][Set ID][ ][Data][Cr]
OK Acknowledgement
* The set transmits ACK (acknowledgement) based on
this format when receiving normal data. At this time, if
the data is data read mode, it indicates present status
data. If the data is data write mode, it returns the
data of the PC computer.
[Command2][ ][Set ID][ ][OK][Data][x]
Error Acknowledgement
* The set transmits ACK (acknowledgement) based on
this format when receiving abnormal data from
non-viable functions or communication errors.
[Command2][ ][Set ID][ ][NG][Data][x]
Transmission / Receiving Protocol
Command Reference List
Data 00: Illegal Code
COMMAND
1
COMMAND
2
DATA
(Hexadecimal)
*
When setting the 17 to 24, a menu does not appear on screen.
* Note : During USB operations such as Dvix or EMF, all com-
mands except Power(ka) and Key(mc) are not executed and
treated as NG.

LG 19LG3100 Specifications

General

Audio system	SRS TruSurround
RMS rated power	6 W
Number of speakers	2
Child lock	Yes
Package weight	6200 g
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Product color	White
LED indicators	Stand-by
Sustainability certificates	ENERGY STAR
Display diagonal	19 \
Display brightness	300 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Contrast ratio (dynamic)	8000:1
Display diagonal (metric)	48 cm
Power consumption (standby)	1 W
Power consumption (typical)	40 W

Weight and Dimensions

Depth (with stand)	189.2 mm
Width (with stand)	458.8 mm
Height (with stand)	391 mm
Weight (with stand)	5000 g
Depth (without stand)	85.4 mm
Height (without stand)	344.5 mm
Weight (without stand)	4800 g
