EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
Connecting a set-top box with an HDMI cable
1
Connecting with an HDMI to DVI cable
1
2
Connect the digital set-top box to
HHDDMMII//DDVVII IINN 11
,
HHDDMMII IINN
22
(Except for 19/22LH20
**
, 19/22LD3
**
, 19/22LG31
**
)
,,
HHDDMMII IINN 33
(Except for 19/22LU40
**,
19/22LU50
**,
19/22/26/32/37/42LH20
**,
19/22/26/32LD3
**,
32/37/42LF25
**,
32/37/42LG2
***,
32/37/42LG33
**,
26LG31
**
) or
HHDDMMII IINN 44
(Only 32/37/42/47LH49
**,
32/37/42/47/55LH50
**,
32/37/42/47LH70
**,
42/47LH90
**,
50/60PS70
**,
50/60PS80
**
) jack on the TV.
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
Select
HHDDMMII11
,
HHDDMMII22
(Except for 19/22LH20
**
,
19/22LD3
**
, 19/22LG31
**
),
HHDDMMII33
(Except for
19/22LU40
**,
19/22LU50
**,
19/22/26/32/37/42LH20
**,
19/22/26/32LD3
**,
32/37/42LF25
**,
32/37/42LG2
***
,
32/37/42LG33
**,
26LG31
**
) or
HHDDMMII44
(Only 32/37/42/47LH49
**,
32/37/42/47/55LH50
**,
32/37/42/47LH70
**,
42/47LH90
**,
50/60PS70
**,
50/60PS80
**
) input
source using the
IINNPPUUTT
button on the remote control.
2
3
1
Connect the digital set-top box to
HHDDMMII//DDVVII IINN 11
jack on the TV.
Connect the audio output of the digital set-top box to
the
AAUUDDIIOO IINN ((RRGGBB//DDVVII))
jack on the TV.
Turn on the digital set-top box.
(
Refer to the owner’s
manual for the digital set-top box.
)
Select
HHDDMMII11
input source using the
IINNPPUUTT
button
on the remote control.
2
3
4
1
GG
Check that your HDMI cable is version 1.3 or higher.
If the HDMI cables don’t support HDMI version 1.3, flicker-
ing or no screen display can result. Please use the latest
cables that support at least HDMI version 1.3.
NOTE
!

LG 19LG3100 Specifications

General

Audio system	SRS TruSurround
RMS rated power	6 W
Number of speakers	2
Child lock	Yes
Package weight	6200 g
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Product color	White
LED indicators	Stand-by
Sustainability certificates	ENERGY STAR
Display diagonal	19 \
Display brightness	300 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Contrast ratio (dynamic)	8000:1
Display diagonal (metric)	48 cm
Power consumption (standby)	1 W
Power consumption (typical)	40 W

Weight and Dimensions

Depth (with stand)	189.2 mm
Width (with stand)	458.8 mm
Height (with stand)	391 mm
Weight (with stand)	5000 g
Depth (without stand)	85.4 mm
Height (without stand)	344.5 mm
Weight (without stand)	4800 g
