TRAINING MANUAL
DLEX8377WM
DLEX8388WM
Page 60
STEAM DRYER
ROLLERS
Remove the top plate.
Remove the front cover.
Remove the tub front.
Remove the drum (if replacing the back
rollers.)
Use an open-end wrench to remove and
replace the shaft and roller.
NOTE:
If the shaft is undamaged, you can
replace only the roller. Squeeze the
triangular retainer to remove and replace
the roller without removing the
shaft from the machine.
Be sure to install the small bushings. These
must be between the roller and the retainer
on both sides of the roller.
See photo.
Some models are supplied with an updated
roller assembly that does not include the
bushings.
These assemblies are interchangeable
across most LG dryer models.
