4. TROUBLE SHOOTING
- 158 -
Copyright © 2011 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4.13 Camera troubleshooting
5M camera control signals are generated by AP_OMAP3630(U301), and Power is supplied by LP8720(U601)
Check the camera conn.
and revonnect thr camera
Camera is OK?
No
END
Yes
START
Yes
Check the camera signals MCLK(TP4),
MIPI_CLK(TP5), MIPI_DATA(TP6)
Yes
Change the camera
Change the main board
No
Check IOVDD(TP1),
DVDD(TP2), AVDD(TP3)
Camera is OK?
END
Yes
No
To Next Page
