12. EXPLODED VIEW & REPLACEMENT PART LIST
- 263 -
Copyright © 2011 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
ordered by SBOM standard on GCSC
Level Location No. Description PartNumber Spec Remark
7 CN101 Connector, I/O ENRY0008801
GU073-5P-SD-E1500 GU073-5P-SD-E1500, 5,
mm, ANGLE LS Mtron Ltd.
7 CN102 Connector, BtoB ENBY0053101
14-5804-014-000-829+ 14, mm, STRAIGHT,
0.40MM, MALE, KYOCERA ELCO KOREA
SALES CO., LTD.
7 U101
IC, Ambient Light
Sensor
EUSY0388201
BH1621FVC BH1621FVC, WSOF6, 5, R/TP,
1.6*1.6 - WSOF6 R/TP 5P - ROHM Semiconductor
KOREA CORPORATION
7
C101,
C102,
C105
Capacitor, Ceramic,
Chip
ECZH0001215
C1005X5R1A105KT000F 1uF 10% 10V X5R -
55TO+85C 1005 R/TP - TDK KOREA
COOPERATION
7
FL102,
FL103
Filter, EMI/Power SFEY0013501
EVRC18S03Q015010R ESD/EMI 0HZ 7.5pF 0H
SMD R/TP AMOTECH CO., LTD.
7 C107
Capacitor, Ceramic,
Chip
ECCH0002001
C1005JB0J104KT000F 0.1uF 10% 6.3V Y5P -
30TO+85C 1005 R/TP - TDK CORPORATION
7 U102 IC, Proximity EUSY0376201
GP2AP002S00F GP2AP002S00F, 8, R/TP SHARP
CORPORATION.
7 C106
Capacitor, Ceramic,
Chip
ECCH0017601
CL05A475MQ5NRNC 4.7uF 20% 6.3V X5R -
55TO+85C 1005 R/TP 0.5MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
7 CN103 Connector, BtoB ENBY0034201
GB042-24S-H10-E3000 24P 0.40MM STRAIGHT
SOCKET SMD R/TP 1M - LS Mtron Ltd.
7 J101 Jack, Phone EAG62831701
KJA-PH-3-0176 4P 4P ANGLE R/TP 3.5M BLACK
5P 6.5x12.6x4.0t, Short Detect, All DIP type KSD
CO., LTD
7 CN102 Connector, BtoB ENBY0051301
14-5804-040-000-829+ 40P 0.40MM STRAIGHT
MALE SMD R/TP 900mM - KYOCERA ELCO
KOREA SALES CO., LTD.
7
VA103,
VA104,
VA105,
VA107,
VA108
Varistor SEVY0010501
IECS0505C040FR 10V 0% 4E-12F 1.0x0.5x0.3
IEC61000-4-1 (ESD) level #4 SMD R/TP
INNOCHIPS TECHNOLOGY
This Chapter is used for reference, Part order is
12.2 Replacement Parts
<Main component>
