18
ENGLISH
Parts and Components
This projector is manufactured using high-precision technology. You may,
however, see tiny black dots and/or bright colored dots (red, blue, or green)
that continuously appear on the projector screen. This is a normal result of the
manufacturing process and does not indicate a malfunction.
Main Unit
Bottom of the Projector
Adjustable leg
3)
IR Receiver
Lens
2)
Vent
1)
Speaker
Joystick Button
Speaker
Focus Ring
Vent
1)
Vent
1)
Mirror
2)
1) Due to the high temperature of vent area, do not get close to the vent area.
2) Do not touch the lens and mirror when using the projector. The lens may be
damaged. (Keep lens away from sharp objects.)
3) Turn the adjustable leg left or right to adjust the angle.
